 Product model  |
 S-200-5  |
 S-200-12  |
 S-200-24  |
 S-200-36  |
|
 Input voltage  |
 AC110/220V  |
 AC110/220V  |
 AC110/220V  |
 AC110/220V  |
|
 Output voltage  |
 DC 5V  |
 DC 12V  |
 DC24V  |
 DC 36V  |
|
 Output current  |
 DC 40A  |
 DC 16.6A  |
 DC 8.3A  |
 DC 5.5A  |
|
 Output power  |
 200 W  |
 200 W  |
 200 W  |
 200 W  |
|
 Product size  |
 199*110*50mm  |
 199*110*50mm  |
 199*110*50mm  |
 199*110*50mm  |
|
 Product weight  |
 900g  |
 900g  |
 900g  |
 900g  |
|
 Product authentication  |
 CE  |
 CE  |
 CE  |
 CE  |
* Price bottom, high reliable, operating temperature bottom, operating temperature - 10℃~+50℃
* The whole world is suitable AC90-250V (47-63Hz) the input voltage, the soft starting current has the suburb to fall the bottom AC input impact.
* The output has the short circuit, the over-load protection, 105%~150% cut-off output, self-recovery, 100% full load aging test.
* DC voltage adjustable range ±10%.
* The start, the rise, maintain the time, 300ms, 50ms, 80ms.
* Insulation strength resistance to pressure; Input output: between 3.5KvAC input and outer covering: between 1.5KvAC output and outer covering: 0.5KvAC one minute.
* The standard of security conforms to GB4943, UL60950, EN60950; The EMC standard conforms to GB9254, EN55015 rank B
